 More Specations
|
DESCRIPTIONS :
◆Contact Rating : 5A With Resistive Load @ 120VAC or 28VDC.
◆Electric Life : 50,000 Make-And-Break Cycles at Full Load.
◆Contact Resistance : 10m Ohm. max. inital @2.4VDC. 100mA for Both Coin Silver
And Gold Plated Contacts.
◆Insulation Resistance : 1,000M Ohm. Min
◆Dielectric Atrength : 1,000V RMS @Sea Level
◆Operating Temperature : -30degree ~ +130degree |
