More Specations

◆ Materials
    Insulator: High Temperature Thermoplast UL94V-0
    Contact: Copper Alloy.
◆ Plating
    Contact : Gold Over Nickel
◆ Electrical
    Voltage Rating: AC 250V (R.M.S)
    Current Rating: 2 Amp
    Insulation Resistance: 1000 Megohms Min
    Dielectric Withstanding Voltage: AC 500V (R.M.S.)
    Contact Resistance: 40 Milliohms Max
◆ Environmental
    Temperature Range: -55℃ To +105℃
