Notebook Connector

Mini PCI DIMM Socket

Available for 5.6mm height

Materials

Insulators:

Insulator shall be Molded of 30% Glass Reinforced L.C.P. or Other High Performance Resins, Rated 94V-0 in

Accordance With UL-94 Contacts:

The Base Material Shall be JIS C5210R-SH, or Other Equivalent Copper Alloys

Electrical

Current Rating:

0.3

Voltage Rating:

25 VAC

Mechanical

Contact Normal Force:

50 gf min.

 Durability:

50 Mating Cycles

Environmental

Temperature Rating:

-50℃ to 90℃
