Compatible With PCMCIA Standard |
|
Matching With JAE Series |
|
Reliable Design on Cable Side for strain Relief Function |
|
|
|
Materials |
|
|
Insulators of Board side: |
UL 94V-0 thermoplastic polyester, color black |
|
|
Insulators of Cable side: |
UL 94V-0 thermoplastic polyester, color black |
|
|
Contacts: |
Phosphor Bronze |
|
|
|
|
|
Electrical |
|
|
Contact Current Rating: |
1.0Amp |
|
|
Contact Ressistance: |
40 milliohms max. |
|
|
Dielectric Withstanding Voltage: |
1000V r.m.s. for 1 minute (Sea level) |
|
|
Insulation Ressistanece: |
1000 Megaohm min |
|
|
|
|
|
Mechanical |
|
|
Contact Retention: |
0.6kgf min |
|
|
Insertion Force: |
2.0 kgf max. for all positions |
|
|
Withdrawal Force: |
0.3 kgf min. |
|
|
|
|
|
Environmental |
|
|
Working Temperature: |
40℃ to 105℃ |
