Compatible With PCMCIA Standard

Matching With JAE Series

Reliable Design on Cable Side for strain Relief Function

Materials

Insulators of Board side:

UL 94V-0 thermoplastic polyester, color black

Insulators of Cable side:

UL 94V-0 thermoplastic polyester, color black

Contacts:

Phosphor Bronze

Electrical

Contact Current Rating:

1.0Amp

Contact Ressistance:

40 milliohms max.

Dielectric Withstanding Voltage:

1000V r.m.s. for 1 minute (Sea level)

Insulation Ressistanece:

1000 Megaohm min

Mechanical

Contact Retention:

0.6kgf min

 Insertion Force:

2.0 kgf max. for all positions

Withdrawal Force:

0.3 kgf min.

Environmental

Working Temperature:

-40℃ to 85℃
