Compatible with PCMCIA Standard

Matching With Honda 15Pos Series

Reliable Design on Latching Mechanism

Materials

Board Mount:

Insulators:UL94V-0 Thermoplastic Polyester, Color Black

Outer Shell:

Copper Alloy

Contacts:

Phosphor Bronze, Selective Gold Plated Over Nickel Underplated

Insulators:

UL 94V-0 Thermoplastic Polyester, Color Black

Outer Plastic Hood:

ABS, Color Black

Inner Metal Shell:

Steel

Electrical

Contact Current Rating:

0.5Amp

Contact Resistance:

40 Millionms Max

Rated Voltage:

30 VAC

Dielectric Withstanding Voltage:

1000V r.m.s. for 1 Min (sea level)

Insulation Resistance:

1000 Megohm Min

Mechanical

Durability:

500 Matings (Office Environment)

Environmental

Temperature Rating:

-40℃ to 105℃

Suggest Wire Size:

30AWG
