 More Specations
|
|
1.5mm high |
|
Easy alocation by rotary actuator |
|
Option for std, top and bottom mount |
|
Reliable robust actuator |
|
|
|
Materials |
|
|
Contact: |
Phosphor Bronze |
|
|
Insulation: |
Heat resistance resin with 30% G.F. UL94V-0 |
|
|
Metal hold down: |
Phosphor Bronze |
|
|
Actuator : |
Heat resistance resin with 30% G.F. UL94V-0 |
|
|
|
|
|
Electrical |
|
|
Current Rating: |
0.5 A |
|
|
LLCR: |
35 mΩ max. ΔR=20 mΩ max. |
|
|
Insulation Resistance: |
500 V DC |
|
|
Dielectric Withstanding Voltage: |
250 VAC AT 60 Hz |
|
|
|
|
|
Mechanical |
|
|
Cable retention force: |
200gf min |
|
|
Durability: |
15 cycles |
|
|
|
|
|
Environmental |
|
|
Temperature Life : |
105 ± 2 ℃ for 96 hr |
|
|
Salt Spray: |
35± 2 ℃ for 48 hr |
|
|
Thermal Shock: |
-55 ± 5 TO 85 ± 5 ℃, Condition A | |
