 More Specations
|
Specifications
˙Circuit : A : (ON)-OFF
˙Rating : 3A 125VAC/1A 250VAC
˙Contact Resistance : 50mΩ(max.)
˙Insulation Resistance : DC 500V 100MΩ(min.)
˙Dielectric Strength : AC 1000V 1 Minute
˙Electrical Life : 5000 Cyales
˙Mechanical Life : 10000 Cycles
˙Terminal Material : Copper,Alloy,silver,Plated
˙Push Force : >0.35Kg
˙Button Color : Red,yellow,Orange,Black,Green |
