 More Specations
|
Specifications
˙Rating : 10A 125VAC/250VAC
16A 250VAC
˙Contact Resistance : 20mΩ(max.)
˙Insulation Resistance : DC 500V 100MΩ(min.)
˙Dielectric Strength : 1500VAC/1 Minute
Materials
˙Housing : Nylon#66 UL 94V-2
˙Rocker : Nylon#66 UL 94V-2
˙Terminal : Copper Alloy Sn or Ag Plated
˙Contactor : Ag Alloy
˙Spring : Music Wire |
