More Specations

Specifications
 ˙Circuit : SPST ON-OFF
 ˙Rating: 6A 125VAC/3A 250VAC
 ˙Contact Resistance : 30mΩ(max.)
 ˙Insulation Resistance : DC 500V 100MΩ(min.)
 ˙Dielectric Strength : AC1000V 1 Minute
 ˙Operation Force : 0.3~0.8Kg
 ˙Operation Life : 10000 Cycle st Full Load
 ˙Operation Temperature Range : ~25 C~+80 C
 ˙Soldering Heat Temperature : 280 C 3 Sec
