 More Specations
|
Materials
◆ Housing: HI-Temp Plastic (UL 94V-0) Beige
Terminal:
◆ Copper Alloy (t=0.20mm)
◆ Gold Plated Over Nickel
Specification:
◆ Current Rating: 0.5A Max
◆ Insulation Resistance: 1000MΩ Min AT 500V DC
◆ Dielectric Withstanding Voltage: 150V AC R.M.S. For One Minute.
◆ Contact Resistance: 50MΩ Max.
◆ Operating Temperature: -40℃ ~ +105℃ |
