More Specations

DESCRIPTIONS :

  ◆Contact Rating : 5A With Resistive Load @ 120VAC or 28VDC.
  ◆Electric Life : 50,000 Make-And-Break Cycles at Full Load.
  ◆Contact Resistance : 10m Ohm. max. inital @2.4VDC. 100mA for Both Coin Silver And Gold Plated Contacts.
  ◆Insulation Resistance : 1,000M Ohm. Min
  ◆Dielectric Atrength : 1,000V RMS @Sea Level
  ◆Operating Temperature : -30degree ~ +130degree
