 More Specations
|
SPECIFICATION MATERIAL
◆ Insulator: Thermal Plastic UL94V-0
◆ Contacts: Copper Alloy
CONTACT PLATING
◆ Underplate: 50μ" Nickel
◆ Contact Area: 5μ" ~ 15μ" Selective Gold
ELECTRICAL
◆ Operation Voltage: 250 VAC Max.
◆ Current Rating: 1 Amps Max.
◆ Contact Resistance: 100 mohms Max.
◆ Insulation Resistance: 1000 Mohms Min. @ 500 VDC
◆ Dielectric Withstanding Voltage: 500 VAC / minute
◆ Operating Temperature: -25°C to +85°C |
