More Specations

SPECIFICATION MATERIAL
    ◆ Insulator: Thermal Plastic UL94V-0
   ◆ Contacts: Copper Alloy
   ◆ CONTACT PLATING Underplate: 50μ" Nickel
   ◆ Contact Area: 5μ" ~ 15μ" Gold Plating
ELECTRICAL
   ◆ Operation Voltage: 5 VDC Max.
   ◆ Current Rating: 0.5 Amps Max.
   ◆ Contact Resistance: 100 mohms Max.
   ◆ Insulation Resistance: 1000 Mohms Min. @ 500 VDC
   ◆ Dielectric Withstanding voltage: 1000 VAC / minute
   ◆ Operating Temperature: -40 °C to + 85 °C
