More Specations

Specification
Poles: 30
Voltage rating: 50V AC/ DC
Current rating: 1A AC/ DC
Withstanding Voltage: 500V AC/minute
Insulation resistance: 100MΩ min
Temperature range: - 25℃ to + 85℃
Contact resistance: 20mΩ max.

Type	Type
Wafer	Terminal
Part No.	Part No.
JS-1266-30	JS-1266-T
Description	Description
Poles: 30 Material: PA46 Q'ty: 1,000 by bag	Material: Phosphor Bronze Finish: Tin pr Gold Plated Thickness: 0.15 mm Q'ty: 15,000 per Reel
