Material and Finish
◆ Plastic Material : High Temperature Plastic,UL94V-0
◆ Contact Material : Copper Alloy
◆ Contact Area Plated : Gold Plated Over Nickel
◆ Solder Area Plated : Tin Plated Over Nickel
◆ Current Rating : 1.5 Amp Max.
◆ Contact Resistance : 30 mohm Max.
◆ Insutation Resistance : 1000 Mohm Min.
◆ Dielectric Withstanding Voltage : 500V AC/minute
◆ Operating Temperature : -40°C TO +85°C
◆ Mating Cycles : 20000 Cycles
|
