Path : Our Products > Connectors > Smart Card Connector > Smart Card Connector Landing Type

	SCL-01

View Enlargement

More Specification >>

Material and Finish
◆ Plastic Material : High Temperature Plastic,UL94V-0
◆ Contact Material : Copper Alloy
◆ Contact Area Plated : Gold Plated Over Nickel
◆ Solder Area Plated : Tin Plated Over Nickel
◆ Current Rating : 1 Amp Max.
◆ Contact Resistance : 100 mohm Max.
◆ Insutation Resistance : 1000 Mohm Min.
◆ Dielectric Withstanding Voltage : 750V AC/minute
◆ Operating Temperature : -40°C TO +85°C
◆ Mating Cycles : 200000 Cycles

Please write down your comment on this product, and click for Inquiry
