More Specification >>
|
Materials :
◆Insulator: P.B.T. With Glass Reinforced UL94 V-0
◆Contact: Phosphor Bronze
◆Shell: Steel
Electrical :
◆Contact Current Rating: 1.5 Amp.
◆Shell Resistance: 50 milliohms max
◆Contact Resistance: 20 milliohms max
◆Insulation Resistance: 500 MΩ min at 500V DC
◆Dielectric Withstanding Voltage: 250 VAC for 1 minute (sea level)
Environmental :
◆Temperature Rating: -20℃ to 85℃
|
