Specification
Voltage rating: 250V AC/DC
Current rating: 3A AC/DC
Withstanding Voltage: 1,000V AC/minute
Insulation resistance: 1,000 MΩ min
Temperature range: -25℃ to +85℃
Contact resistance: 20mΩ max
| Type |
Type |
| Housing |
Terminal |
| Part No. |
Part No. |
| JS-1163/JS-1164/JS-1164B/JS-1164BN |
JS-1163-T |
| Description |
Description |
|
Poles: JS-1163:2-30
JS-1164:4-80
JS-1164B/JS-1164BN:4-50
Material: Nylon 66 UL94V-2
Q'ty: 1,000 pcs/bag
|
Applicable wires: AWG #26 ~ 30
Material: Phos. bronze
Finish: Gold plated
Thickness: 0.2 mm
Q'ty: 20,000 pcs/reel
| |
|
