Specification
Voltage rating: 250V AC,DC
Current rating: 2.5A, AC DC
Withstanding Voltage: 800V AC/minute
Insulation resistance: 1000 M min
Temperature range: -25°C ~ +85°C
Contact resistance: 20mΩ max
| Type |
Type |
| Housing |
Terminal |
| Part No. |
Part No. |
JS-1137 , JS-1137B(180° )
JS-1137R(90° ) |
JS-1137-T , JS-1137B-T
JS-1137-TP,JS-1137B-TP,JS-1137R-TP (Stamping Before Tin Plated) |
| Description |
Description |
Poles: 2 - 16
Material: Nylon 66 UL 94V-0
Q'ty: 1000 pcs/bag |
Applicable wires: AWG #22 ~ 28
Material: Brass
Finish: Tin / plated
Thickness: 0.2 mm
Q'ty: 10,000 pcs/reel | |
|
