Feature
◆ Plastic Material : High Temperature Plastic,UL94V-0
◆ Contact Material : Copper Alloy
◆ Contact Area Plated : Gold Plated Over Nickel
◆ Solder Area Plated : Tin Plated Over Nickel
◆ Current Rating : 0.5 Amp Max.
◆ Contact Resistance : 10 mohm Max.
◆ Insutation Resistance : 100 Mohm Min.
◆ Dielectric Withstanding Voltage : 300V AC/minute
◆ Operating Temperature : -55°C TO +125°C
|
