Specification
Poles: 40 , 50
Voltage rating: 80V AC
Current rating: 1.0A
Withstanding Voltage: AC 250V / minute
Insulation resistance: 500MΩ Min
Temperature range: -35℃ to 85℃
Contact resistance: 30MΩ MAX
| Type |
Type |
Type |
| Housing |
Wafer |
Terminal |
| Part No. |
Part No. |
Part No. |
| JS-2453-XX |
JS-2454-XX |
JS-2453-TG |
| Description |
Description |
Description |
Poles: 40 , 50
Material: PA46 UL 94V0
Q'ty: 1,000 pcs/Bag |
Poles: 50
Material: PA46 UL 94V0
Q'ty: 5,000 pcs/Bag |
Applicable wires: AWG# 28-36
Material: Phos. Bronze
Q'ty: 15,000 pcs/Reel |
|
