| Compatible with PCMCIA Standard |
| Matching With Honda 15Pos Series |
| Reliable Design on Latching Mechanism |
| |
| Materials |
| |
Board Mount: |
Insulators:UL94V-0 Thermoplastic Polyester, Color Black |
| |
Outer Shell: |
Copper Alloy |
| |
Contacts: |
Phosphor Bronze, Selective Gold Plated Over Nickel Underplated |
| |
Insulators: |
UL 94V-0 Thermoplastic Polyester, Color Black |
| |
Outer Plastic Hood: |
ABS, Color Black |
| |
Inner Metal Shell: |
Steel |
| |
|
|
| Electrical |
| |
Contact Current Rating: |
0.5Amp |
| |
Contact Resistance: |
40 Millionms Max |
| |
Rated Voltage: |
30 VAC |
| |
Dielectric Withstanding Voltage: |
1000V r.m.s. for 1 Min (sea level) |
| |
Insulation Resistance: |
1000 Megohm Min |
| |
|
|
| Mechanical |
| |
Durability: |
500 Matings (Office Environment) |
| |
|
|
| Environmental |
| |
Temperature Rating: |
-40℃ to 105℃ |
| |
Suggest Wire Size: |
30AWG |
