| Industry Standard |
| For 4 Pos |
| |
| Materials |
| |
Insulator: |
L.C.P. With Glass Reinforced UL94 V-0. |
| |
Contacts: |
Phosphor Bronze C5191R-H. |
| |
|
|
| Electrical |
| |
Contact Current Rating: |
1 Amp |
| |
Voltage Rating: |
30V AC. |
| |
Contact Resistance: |
50 Milliohms Max |
| |
Insulation Resistance: |
100 MΩ at 100V DC |
| |
Dielectric Withstanding Voltage: |
100 VAC for 1 Min (sea level) |
| |
|
|
| Mechanical |
| |
Contact Retention Force |
800 gf Min |
| |
Total Insertion Force: |
1 Kgf Max |
| |
Total Withdrawal Force: |
0.5 Kgf Min |
| |
|
|
| Environmental |
| |
Temperature Rating: |
-55℃ to 105℃ |
|
