| Horizontal 0.5mm Pitch |
| SMT Type |
| Available from 5 pos to 50pos |
| |
| Materials |
| |
Insulator: |
L.C.P. With 30% Glass Reinforced UL94 V-0 |
| |
Contacts: |
Phosphorus Bronze C5191R-H |
| |
Hold Down: |
Phosphor Bronze C5191R-H |
| |
|
|
| Electrical |
| |
Contact Current Rating: |
0.5Amp |
| |
Contact Ressistance: |
35 millionhms max. |
| |
Dielectric Withstanding Voltage: |
250V AC. for 1 minute (sea level) |
| |
Insultaion Ressistanece: |
100 Megohm min at 500 V DC. |
| |
|
|
| Environmental |
| |
Working Temperature: |
-20℃ to 85℃ |
