| Specifications |
| |
˙ |
Rating |
: |
K : 6A 125VAC/3A 250 VAC (UL CSA) |
| |
|
|
|
H : 10A 125 VAC/6A 250 VAC (UL~SEA) |
| |
|
|
|
L : 5A 125 L (Inrush Current 80A) |
| |
|
|
|
T : 16A 125 VAC/10A 250 VAC T105 |
| |
˙ |
Contact Resistance : 20mΩ (max.) |
| |
˙ |
Insulation Resistance : DC 500V 100MΩ (max.) |
| |
˙ |
Dielectric Strength : 1500VAC/1 Minute |
| |
˙ |
Safety Approval : UR, CSA, VDE, Demko , Nemko, Semko, Femko, SEV |
