AC Fan > 180mm to 254mm

205x205x72
－ View Enlargement －
RANGING FROM 80x80x25 TO 205x205x72mm,WITH 110-220 VOLTAGE, CAN BE USED FOR HOME APPLIANCE, INDUSTRIAL EQUIPMENT, and MEDICAL INSTRUMENT AND OTHER APPLICATION.


Feature:
1.Powerful CFM with higher torque.
2.Optimized blade design for better performance.
3.Long life with patented Hypro bearing.
4.Full range of different dimension.

P.S Bearing type : ◎= Ball "B", ※ = Sleeve "S", ○ = 1B1S "B(S)", ● = Hyprobearing "X"

Model No. Voltage(V) Current(A) Power(W) Speed(rpm) Maximum AirFlow Maximum Pressure Noise(dB/A) Bearing Type
(CMM) (CFM) (InAq) (mmAq) B S B(S) X
KK2071HB
110-115/50
0.6
65
2800
 16.4 580 0.98 25
60+-2
 ◎
110-115/60
1
102
3000
 18.3 647 1.1 28
60+-2
 ◎
KK2072HB
220-240/50
0.3
65
2800
 16.4 580 0.98 25
60+-2
 ◎
220-240/60
0.49
102
3000
 18.3 647 1.1 28
60+-2
 ◎
