AC Fan > 180mm to 254mm

180x180x65
－ View Enlargement －
RANGING FROM 80x80x25 TO 205x205x72mm,WITH 110-220 VOLTAGE, CAN BE USED FOR HOME APPLIANCE, INDUSTRIAL EQUIPMENT, and MEDICAL INSTRUMENT AND OTHER APPLICATION.


Feature:
1.Powerful CFM with higher torque.
2.Optimized blade design for better performance.
3.Long life with patented Hypro bearing.
4.Full range of different dimension.

P.S Bearing type : ◎= Ball "B", ※ = Sleeve "S", ○ = 1B1S "B(S)", ● = Hyprobearing "X"

Model No. Voltage(V) Current(A) Power(W) Speed(rpm) Maximum AirFlow Maximum Pressure Noise(dB/A) Bearing Type
(CMM) (CFM) (InAq) (mmAq) B S B(S) X
KK1861HB
110-115/50
0.53
50
2650
 10.8 380 0.79 20
60+-2
 ◎
110-115/60
0.5
52
3200
 13 450 1.02 26
60+-2
 ◎
KK1862HB
220-240/50
0.23
43
2650
 10.8 380 0.79 20
60+-2
 ◎
220-240/60
0.24
52
3200
 13 450 1.02 26
60+-2
 ◎
