- Interconnects Connectors Pin headers
-
-
5001 (DUAL ROW) SERIES
2.54MM PITCH PIN HEADER
Description
MATERIAL:
INSULATOR : PBT + 30% GLASS FIBER,
UL 94V-0 RATED.
CONTACT : BRASS.
ELECTRICAL CHARACTERISTICS:
CURRENT RATING : 1 AMP.
WITHSTANDING VOLTAGE : AC 750V R.M.S.
INSULATOR RESISTANCE : 5000 MEGOHMS MIN.
CONTACT RESISTANCE : 20 MILLIOHMS MAX.
OPERATING TEMPERATURE : -55°C ~ +105°C
INSULATOR : PBT + 30% GLASS FIBER,
UL 94V-0 RATED.
CONTACT : BRASS.
ELECTRICAL CHARACTERISTICS:
CURRENT RATING : 1 AMP.
WITHSTANDING VOLTAGE : AC 750V R.M.S.
INSULATOR RESISTANCE : 5000 MEGOHMS MIN.
CONTACT RESISTANCE : 20 MILLIOHMS MAX.
OPERATING TEMPERATURE : -55°C ~ +105°C
Supplier Information
Chufon Technology Co., Ltd.
TEL : 886-2-29991367 FAX : 886-2-299918359F., No. 145-21, Zhongzheng Rd., Xinzhuang Dist., New Taipei City 242008, Taiwan
Web-Site : http://www.chufon.com.tw/
E-Mail : sales@chufon.com.tw
